Operating temperature:

-20… +50℃

Storage temperature:

-25… +85℃

Working humidity:

10%…90%

Store humidity:

5%…95%

Driver lifetime:

at Tc 75℃: 50,000 hrs @ performance range (0.2% / 1,000 h failure rate)

Maximum Tc temperature:

85℃

Rated input voltage range:

120…277 Vac; performance range

Max.input voltage range:

108...305 Vac; operational safety range

Rated input current DC range:

50/60 Hz

Performance / Operational safety:

47...63 Hz

Max. input current:

0.32 A @ 120 Vac

Withstand voltage:

I/p-O/p: 1.6 kVac, < 5 mA 60 sec,

I/p-Earth: 1.6 kVac, < 5 mA 60 sec,

O/p-Earth: 0.5 kVac, < 5 mA 60 sec

THD:

≤ 20%

Inrush current [Aµs]:

12.9 A, 116 μs

MCB Quantity B10A:

26

MCB Quantity C10A:

26

MCB Quantity B16A:

42

MCB Quantity C16A:

42

Output current range:

NFC control adjusts the current: 100…600 mA

Default output current.:

600 mA

Output voltage range:

28…52 Vdc

Noise level:

< 20 dB, at full load @ 100 cm distance

Output current tolerance:

± 5% at rated input voltage performance range

No load output voltage:

≤ 60 Vdc

Ripple output current:

5% (ripple = peak/average total 100 Hz)

Dimming mode:

0/1-10V (programmable)

Dimming method:

Amplitude dimming

Dimming current range:

1%...100% (6...600 mA)
